eBPF Linux: How It Works, Use Cases & Best Practices

eBPF (extended Berkeley Packet Filter) is a Linux kernel technology that allows for dynamic and efficient tracing of various system events.

What Is eBPF in Linux?

eBPF (extended Berkeley Packet Filter) is a Linux kernel technology that allows for dynamic and efficient tracing of various system events, such as network packets, function calls, and other system events. eBPF programs can be written in a restricted C-like language and compiled into bytecode that can be executed safely inside the kernel.

eBPF (extended Berkeley Packet Filter)

eBPF was originally designed to be a more powerful and flexible replacement for the traditional BPF (Berkeley Packet Filter) technology used for network packet filtering in Linux. However, eBPF has since been extended to support other use cases such as system tracing, performance analysis, security monitoring, and more.

One of the advantages of eBPF is its ability to dynamically load and unload programs without requiring a kernel restart. This makes it easier for administrators to debug and diagnose issues in production environments. Additionally, eBPF has a low overhead, which means that it can be used in performance-sensitive scenarios.

eBPF has become increasingly popular in the Linux ecosystem, and it is now widely used in various open-source tools and projects, including the Linux kernel itself.

This is part of a series of articles about DevSecOps

In this article:

eBPF Use Cases

Here are some of the primary uses of eBPF.


eBPF allows organizations to build a better security system by providing a way to monitor and filter system events in real-time, enabling early detection and response to potential security threats. eBPF programs can be used to monitor network traffic, system calls, and other system events, allowing for better visibility into potential security risks. They provide views of networking activities at the packet and socket levels. Additionally, eBPF can be used to enforce security policies by blocking or modifying certain system events based on predefined rules.

Monitoring and Observability

BPF improves monitoring and observability by allowing for dynamic and efficient tracing of various system events. eBPF programs can be used to trace network packets, system calls, function calls, and other events in real-time, enabling deep visibility into system behavior.

eBPF achieves this deep visibility while minimizing system overhead by executing programs safely within the kernel and providing a low-level interface for interacting with system events. This allows for efficient and flexible instrumentation of system behavior, enabling organizations to better monitor and observe their systems.


eBPF fulfills the packet processing needs of networking solutions by allowing for efficient and flexible packet filtering, routing, and modification within the Linux kernel. eBPF programs can be used to process packets at various stages of the networking stack, enabling a wide range of use cases, including firewalls, load balancers, and network monitoring tools. The low overhead and dynamic loading capabilities of eBPF make it a powerful tool for building performant and scalable networking solutions.

Performance Profiling and Tracing

eBPF enables organizations to profile and trace the runtime behavior of systems and applications by allowing the creation of custom tracing tools that can capture and analyze a wide range of system events. eBPF programs can be used to trace function calls and produce comprehensive data structures based on statistics, without requiring large data exports.

Additionally, eBPF can be used to collect data for offline analysis, allowing for more comprehensive and in-depth performance analysis.

Using eBPF to Secure Linux Systems

eBPF (Extended Berkeley Packet Filter) has emerged as a powerful and versatile technology that provides a significant boost to the security landscape in Linux. By allowing the attachment of small, efficient programs to various kernel hooks, eBPF enables fine-grained control, monitoring, and analysis of system behavior. In this section, we will explore the various ways eBPF powers security in Linux systems.

  • Visibility and monitoring: eBPF facilitates the collection of system data and metrics by attaching programs to tracepoints, kprobes, and uprobes. This level of visibility allows security teams to detect unusual behavior, identify potential threats, and analyze the attack surface. Additionally, eBPF offers real-time monitoring capabilities that help administrators respond to incidents more effectively.
  • Network security: eBPF’s roots in packet filtering make it a natural fit for network security applications. With eBPF, developers can create programs that inspect, filter, or modify network packets in the kernel, without the need for additional user-space components. This allows for the implementation of custom security policies, intrusion detection and prevention systems (IDS/IPS), and traffic analysis tools that operate at high speed and low latency.
  • Container security: As containerization and microservices architectures become increasingly popular, securing these environments becomes critical. eBPF can be used to monitor and enforce security policies within containerized environments by attaching programs to cgroup hooks. This allows for fine-grained control over process execution, resource usage, and network activity within containers, as well as facilitating isolation between container instances.
  • Intrusion detection and prevention: By leveraging eBPF’s ability to intercept syscalls and other kernel events, security teams can implement advanced intrusion detection and prevention systems. For example, eBPF can be used to monitor file system activity, restricting unauthorized access or modification of sensitive data. Additionally, eBPF can be used to detect and block attempts to exploit kernel vulnerabilities, such as buffer overflows or use-after-free attacks.
  • Policy enforcement: eBPF enables the enforcement of security policies at both the user and kernel level. Custom eBPF programs can be created to enforce access controls, regulate resource usage, and protect sensitive system components from tampering. By attaching eBPF programs to LSM (Linux Security Module) hooks, administrators can implement and enforce additional security policies beyond those provided by traditional LSMs like SELinux or AppArmor.
  • Incident response and forensics: eBPF can be employed to assist in incident response and digital forensics efforts. By attaching eBPF programs to tracepoints or kprobes, investigators can collect detailed information about system activity and state during an incident. This data can be invaluable for understanding the scope and nature of an attack, as well as aiding in the development of targeted remediation strategies.

Best Practices for Using eBPF on Linux

Keep eBPF Programs Small and Focused

eBPF programs should be designed to perform a specific task, such as monitoring a particular system call or network packet. Keeping eBPF programs small and focused helps to improve performance and reduce the risk of errors.

It is important to avoid creating complex eBPF programs that perform multiple tasks, as this can make them difficult to debug and maintain. By keeping eBPF programs small and focused, users can ensure that they are efficient, reliable, and easy to work with.

Test eBPF Programs Thoroughly

Before deploying eBPF programs, it is important to thoroughly test them in a non-production environment. This can help to identify bugs, performance issues, and compatibility problems before they affect critical systems.

It is also important to test eBPF programs under a variety of different conditions, including high traffic loads, network congestion, and other scenarios that may affect their performance. This can help to ensure that eBPF programs work correctly and reliably in real-world conditions.

Use Kernel-Compatible Versions of eBPF Tools

eBPF tools, such as the BPF Compiler Collection (BCC) and libbpf, should be used in versions that are compatible with the kernel being used. This helps to ensure that the tools work correctly and do not cause compatibility issues.

It is important to ensure that the versions of eBPF tools being used are compatible with the kernel version and configuration being used. Incompatible versions of eBPF tools can cause errors, performance issues, and other problems.

Monitor eBPF Program Performance

eBPF programs can consume significant system resources, so it is important to monitor their performance and resource usage. This can be done using tools such as the eBPF monitoring tool BPFTrace.

By monitoring eBPF program performance, users can identify potential performance bottlenecks and resource constraints, and take steps to optimize eBPF program performance and resource usage.

Use eBPF With Other Monitoring and Security Tools

eBPF can be used in conjunction with other monitoring and security tools, such as Prometheus and Grafana, to provide a more comprehensive view of system activity.

By combining eBPF with other monitoring and security tools, users can gain deeper insights into system activity and identify potential security threats or performance issues more quickly and easily.
